Smaart v8 is the Industry Leading, Dual Platform (Mac & PC), FFT-Based Audio Analysis Software. At its core, Smaart is a computer based dual-channel FFT platform that we use in our work as audio engineers to view the frequency content of signals [].

1 Controlling the JBL Professional DSC260 System Controller Using SIA-Smaart Pro SIA Software Company, Inc. An EAW Company The SIA-Smaart Pro Real-Time module can control crossover and delay functions on the DSC260 as well as output EQ, limiter, gain and phase compensation.

This document discusses details of the Real-Time module s external device control interface specific to the DSC260. More general information about controlling external devices from Smaart Pro can be found in the SIA-Smaart Pro user s manual or the Real-Time Module help file. Preparing a DSC260 for Remote Control The first step in preparing a DSC260 system controller for remote control using SIA-Smaart Pro is to check the version number of the firmware (device-specific software stored in nonvolatile memory) currently running on the unit you want to control. The firmware version shipped with most DCS260s currently in the field does not support external control of this device and will need to be updated.

The DSC260, the firmware version, actually consisting of two separate numbers, appears briefly on the front panel display during boot-up. When you first power the unit up, you should see something like this: JBL DSC-260 B0.12 A1.01 The number beginning with B is the boot version. The number beginning with A is the application version the field-updatable software. Make a note of both numbers. If the application number is 1.05b or later, the DSC260 is ready for remote control and you can skip ahead to Making control connections on page 2.

If the application number is earlier than 1.05b, you will need to update the firmware. Updating the Firmware To update the firmware in the DSC260, you will need the following three items: 1. An RS-232 serial null modem cable. RS-232 is the serial communication standard used in virtually all Windows/IBM compatible computers. A null modem cable is a special type serial cable with the terminal ready and modem ready lines crossed so that the port is held open at all times when two devices are connected.

The DSC260 s serial input (labeled RS232) requires a 9-pin female D connector. The serial (COM) port on your computer, could be a 9- or 25-pin, male or female D connector (only 9 of the pins in a 25-pin serial port are actually used). You should be able to purchase the cable and/or adapters you need from virtually any computer store. The 'Flash' loader application, 626loadr.exe, used to load the new firmware program into the DSC260's nonvolatile memory 3.

The new firmware file for the DSC260 The Flash loader program and updated firmware file for the DSC260 are available for download from the JBL Professional web site ( or the downloads section of the SIA Software Company, Inc. 2 Controlling the JBL Professional DSC260 System Controller Using SIA-Smaart Pro revision 1, 8/99 Page 2 Once you have obtained the necessary software and cable, follow the steps below to upload the new program to the DSC260.

Step 1: Connect the DSC260 to your computer. Connect the serial port (labeled RS232) on the rear panel of the DSC260 to a serial (COM) port on your computer using the null modem cable. If the Boot version number (the number beginning with B displayed on the DSC260 s front panel display on power up) is B0.13 or later you can skip to Step 2 below. If the Boot software is B0.12 or earlier then you will have to disconnect the DSC260 s power cable and reconnect it while holding down the Recall and Mute4 keys.
