Protek 6510 Oscilloscope Service Manual

Protek 6502 Oscilloscope Manufacturer Model 6502 Date 1979 Category Group Description 20 MHz OSCILLOSCOPE Information This compact, light weight model 6500 series has a frequency range of DC-60MHz, [DC-40MHz] or (DC-20MHz), and offers the following features: (1) Wide frequency range: Frequencies up to DC-60MHz, [DC-40MHz] or (DC-20MHz). (2) High sensitivity: 1mV/div (3) Large size CRT: Waveforms are easy to read, on the large 6-inch CRT with an internal graticule scale. (4) Scale: Waveforms are parallax-free with the CRT’s internal graticule scale (5) Alt Mag The normal( 1) and the 10( 5) magnified waveforms can be displayed simultaneously. (6) Alt Trig: Stabilized triggering is accomplished even with two unrelated signals. (7) TV synchronization: Stable TV signals are displayed using new circuitry. (8) Auto focus: Focus deviation is automatically corrected. Manual Type Service Manual Pages 65 Size 5.86 Mbytes (6142660 Bytes) Language english Revision Manual-ID/Number Date 1979 Quality Scanned document, reading partly badly, partly not readable.

Upload date 03 October 2015 MD5 ca77392c6dba5bca1729069e047ce81c Downloads 1459 since 03 October 2015 Information 1 Features 2 Configuration 3 Precautions to be taken to ensure long life 4 How to display to trace 5 Specifications 6 Maintenance, Repair and Storage 7 Test Equipment Required 8 Initial Starting Procedure 9 SYSTEM 10 DISPLAY 11 VERTICAL SYSTEM 12 HORIZONTAL SYSTEM 13 Electrical parts arrangment(with adjustment locations) 14 Block diagram 15 Schematic diagrams 16 Parts list. Manual Type User Manual Pages 47 Size 4.85 Mbytes (5081859 Bytes) Language english Revision Manual-ID/Number Date Quality Scanned document, all readable. Upload date 03 October 2015 MD5 ca2342eea2c332873f5d05f81fce8ed9 Downloads 722 since 03 October 2015 Information 1. Precautions to be taken to ensure long life. 5 4 Description of operating controls. How to display a trace. Signal connections.
